IMSA-13103B-12Y901

Headers, Male Pins Overview

The IMSA-13103B-12Y901 is a surface mount right-angle header connector manufactured by IRISO USA Inc. It features a 12-position single-row configuration with a 2.00mm pitch. The connector utilizes square male pins with tin plating on copper alloy contacts, housed in black PPS insulation. Rated for 50VAC and 3A, it operates within a temperature range of -40°C to 125°C. Key mechanical attributes include a 6.50mm insulation height, latch holder retention, and fixed solder tail design. The component is RoHS3 compliant and classified under MSL Level 1.

Headers, Male Pins Feature Summary

• Surface mount right-angle design with fixed solder tails for stable board-level mounting
• Positive locking latch holder mechanism ensures secure mating stability
• Four-wall shielded housing provides structural protection and alignment
• Tin-plated square contact terminals offer reliable electrical conductivity

Headers, Male Pins Applications

• Board-to-cable interconnections
• Board-to-wire connections
• Consumer electronic device assemblies
• Automotive interior equipment interfaces

Headers, Male Pins Procurement Notes

Verify the specific suffix Y901 against official IRISO documentation to confirm exact pin count and orientation requirements. Ensure compatibility with mating connectors regarding latch holder engagement and four-wall shielding dimensions. Confirm that the surface mount footprint matches the target PCB layout specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a right-angle surface mount header is required for board-to-wire applications. The 2.00mm pitch and 12-position count suit compact layouts needing positive locking retention. Consider the 6.50mm insulation height and four-wall shield for environments requiring robust mechanical stability and alignment during mating cycles.

Headers, Male Pins Part Context

This part belongs to the IMSA-13103B series, which focuses on wire-to-board connectivity solutions. The series emphasizes durable construction with latch holders and fixed solder tails. IRISO designs these connectors for high-reliability applications in consumer electronics and automotive sectors, prioritizing stable board-level mounting and repeated mating performance.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
