IMSA-13103B-20Y900

$1.54

Description：HEADER SMT RA 20POS KEY-A
Series：13103B
Mfr：IRISO USA Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:fca65bf4e9a5 Category: Headers, Male Pins Brand: IRISO USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IMSA-13103B-20Y900 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists IRISO USA Inc.. Its product description is HEADER SMT RA 20POS KEY-A. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for IMSA-13103B-20Y900

Description：HEADER SMT RA 20POS KEY-A
Series：13103B
Mfr：IRISO USA Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Connector Type：Plug
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：20
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Latch Holder
Contact Length - Mating：-
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.256" (6.50mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：39.4µin (1.00µm)
Contact Finish - Post：Tin
Contact Material：Copper Alloy
Insulation Material：Polyphenylene Sulfide (PPS)
Features：Solder Retention
Operating Temperature：-40°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：50VAC

Headers, Male Pins datasheet and documents for IMSA-13103B-20Y900

IMSA-13103B-20Y900

Headers, Male Pins Overview

The IMSA-13103B-20Y900 is a surface mount right-angle header connector manufactured by IRISO USA Inc. It features a 20-position single-row configuration with a 2.00mm (0.079 inch) mating pitch. The connector utilizes square male pin contacts made of copper alloy, finished with tin plating at a thickness of 1.00µm (39.4µin). Designed for wire-to-board applications, it operates within a temperature range of -40°C to 125°C and supports a rated current of 3A at 50VAC. The housing is constructed from black polyphenylene sulfide (PPS) with an insulation height of 6.50mm.

Headers, Male Pins Feature Summary

Positive locking mechanism ensures secure mating stability
Four-wall shielding design provides comprehensive contact protection
Fixed solder tail structure facilitates reliable surface mount assembly

Headers, Male Pins Applications

Wire-to-board interconnections in electronic assemblies
Surface mount technology (SMT) circuit board integration
Industrial control system signal routing

Headers, Male Pins Procurement Notes

Verify the specific part number suffix against official manufacturer documentation to confirm exact pin count and orientation. Ensure compatibility with automated SMT placement equipment specifications. Confirm RoHS3 compliance status through certified datasheets prior to procurement. Validate thermal resistance ratings against intended operating environment requirements.

Headers, Male Pins Selection Notes

Select this component for high-density PCB layouts requiring robust mechanical retention. The right-angle form factor optimizes spatial efficiency in constrained enclosures. Verify that mating connectors match the 2.00mm pitch and keying specifications. Consider the fixed solder tail design for permanent mounting applications where vibration resistance is critical.

Headers, Male Pins Part Context

This connector belongs to the 13103B series, designed for positive locking wire-to-board connections. The series emphasizes reliability in industrial environments through shielded contact designs. It complements other IRISO solutions for complete interconnect systems requiring secure signal transmission.
