IN-P23CTJG

LED Indication - Discrete Overview

The IN-P23CTJG is a surface-mount green LED manufactured by Inolux, housed in a PLCC-2 package with dimensions of 3.2 mm x 2.8 mm x 0.7 mm. It emits light at a dominant wavelength of 525 nm with a forward voltage of 3.2 V and luminous intensity of 4.5 cd. The component features a clear rectangular lens and operates within a temperature range of -40°C to 80°C.

LED Indication - Discrete Feature Summary

• Compact SMD form factor suitable for space-constrained designs
• High brightness output with clear colorless lens
• RoHS compliant lead-free construction

LED Indication - Discrete Applications

• General indicator lighting
• Electronic device status indication
• Consumer electronics displays

LED Indication - Discrete Procurement Notes

Verify the specific datasheet version from Inolux to confirm current electrical characteristics and mechanical tolerances. Ensure compatibility with standard SMT reflow profiles and check for any updated environmental compliance certifications prior to final procurement decisions.

LED Indication - Discrete Selection Notes

Select this component when a compact green indicator is required. Consider the 525 nm wavelength for visibility needs and the PLCC-2 package for standard mounting processes. Evaluate thermal management requirements based on the specified operating temperature range.

LED Indication - Discrete Part Context

This part belongs to Inolux's line of single-color surface-mount LEDs. It utilizes a dome lens design typical for PLCC-2 packages, providing efficient light emission. The series offers various color options, with this specific model focusing on green spectrum applications.

LED Indication - Discrete Replacement Considerations

Cross-reference with other 1411 (2835 metric) green LEDs from different manufacturers if supply constraints exist. Verify pinout compatibility and spectral consistency before substituting with alternative PLCC-2 packages.
