IP3088CX15,135

Overview

The IP3088CX15,135 is an EMI filter circuit manufactured by Nexperia. It utilizes a low-pass LC (Pi) technology with a total inductance of 40nH and a total capacitance of 42pF. The component operates within a frequency range of 800 MHz to 3 GHz. It features SMD/SMT termination and is housed in a WLCSP-15 package. The device supports a minimum operating temperature of -40°C and a maximum of +85°C.

Feature Summary

• Provides electromagnetic interference filtering using low-pass LC Pi topology
• Designed for surface mount integration via WLCSP-15 packaging
• Operates across specified industrial temperature ranges

Applications

• Consumer home audio systems
• Industrial building automation controllers
• Mobile computer hardware interfaces

Procurement Notes

Verify current availability status as the product may be subject to obsolescence or limited supply constraints. Confirm RoHS compliance details through official documentation before finalizing procurement plans. Ensure compatibility with existing design specifications regarding package type and thermal requirements.

Selection Notes

Select this component for applications requiring compact EMI suppression in high-frequency signal paths. The WLCSP-15 form factor suits space-constrained designs. Verify that the 40nH/42pF parameters align with target noise frequencies between 800 MHz and 3 GHz.

Part Context

This component belongs to the EMI Filter Circuits category under Nexperia's portfolio. It serves as a passive filtering solution for protecting sensitive electronics from radio frequency interference. The part is distinct from active wireless transceivers or processing units found in broader NXP product lines.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult manufacturer resources for direct equivalents if this specific variant is discontinued.
