Product Detailed Parameters
- Description：IP4254CZ8-4 - Data Line Filter
- Series：-
- Mfr：Nexperia USA Inc.
- Package：Bulk
- Type：-
- Filter Order：-
- Technology：-
- Number of Channels：-
- Center / Cutoff Frequency：-
- Attenuation Value：-
- Resistance - Channel (Ohms)：-
- Values：-
- ESD Protection：-
- Operating Temperature：-
- Applications：-
- Voltage - Rated：-
- Mounting Type：-
- Package / Case：-
- Size / Dimension：-
- Height：-
- Current：-
- Grade：-
- Qualification：-
Download product information
Overview
The IP4254CZ8-4-TTL,132 is a second-order low-pass EMI/RFI filter utilizing RC Pi network technology. It provides integrated electrostatic discharge (ESD) protection for four data lines. The component is housed in an UDFN-8-EP package with dimensions of 1.4x1.7 mm. This device is designed to suppress electromagnetic interference while protecting sensitive interfaces from voltage transients.
Feature Summary
- Integrates EMI filtering and ESD protection in a single compact footprint
- Employs RC Pi topology for effective high-frequency noise suppression
- Provides robust transient protection for multiple data channels simultaneously
Applications
- High-speed data interface protection
- USB port EMI filtering and surge protection
- Consumer electronics signal line conditioning
Procurement Notes
Verify the exact suffix designation as availability status may vary between distributors. Confirm package orientation and pinout compatibility during integration. Check for obsolescence notices or end-of-life announcements prior to final design approval to ensure long-term supply chain stability.
Selection Notes
Select this component when simultaneous EMI attenuation and ESD protection are required for multi-line data interfaces. Ensure the operating voltage range matches the target system specifications. Verify that the parasitic capacitance values meet the bandwidth requirements of the high-speed signals being protected.
Part Context
This part belongs to Nexperia's family of integrated EMI filters with ESD protection. These components consolidate discrete passive components and protection diodes into a single surface-mount device. They are engineered to reduce board space and simplify assembly processes for portable and compact electronic devices requiring reliable signal integrity.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Consult official Nexperia resources for cross-reference information or equivalent alternatives within the same product family.
