Product Detailed Parameters
- Description：FILTER RC(PI) 47 OHMS ESD SMD
- Series：-
- Mfr：NXP USA Inc.
- Package：Bulk
- Type：Low Pass
- Filter Order：2nd
- Technology：RC (Pi)
- Number of Channels：3
- Center / Cutoff Frequency：-
- Attenuation Value：-
- Resistance - Channel (Ohms)：47, 100
- Values：R = 47Ohms, 100Ohm, C = 6pF
- ESD Protection：Yes
- Operating Temperature：-30°C ~ 85°C
- Applications：Data Lines for Mobile Devices
- Voltage - Rated：-
- Mounting Type：Surface Mount
- Package / Case：8-UFDFN Exposed Pad
- Size / Dimension：0.067" L x 0.053" W (1.70mm x 1.35mm)
- Height：0.022" (0.55mm)
- Current：-
- Grade：-
- Qualification：-
Download product information
Overview
The IP4264CZ8-10-TTL132 is a three-channel RC low-pass filter array manufactured by NXP USA Inc. It integrates resistors and capacitors to form a second-order passive EMI/RFI filter structure. The component features resistor values of 47 Ohms, 100 Ohms, and 6pF capacitance per channel. It is housed in an 8-UFDFN package with an exposed pad, designed for data line filtering applications requiring compact footprint solutions.
Feature Summary
- Integrates three independent RC low-pass filter channels within a single compact package
- Provides second-order attenuation characteristics for effective EMI and RFI suppression
- Designed specifically for passive data line filtering applications
Applications
- Data line filtering in embedded communication systems
- EMI suppression for integrated (U)SIM card interfaces
- RFI protection for high-speed digital signal lines
Procurement Notes
Verify the complete part number including the suffix TTL132 to ensure correct packaging and tape-and-reel configuration. Confirm that the 8-UFDFN package dimensions match the target PCB layout. Check RoHS compliance status against current regulatory requirements for the intended market. Ensure thermal management considerations account for the exposed pad design during assembly.
Selection Notes
Select this component when a multi-channel passive filter solution is required for space-constrained designs. The integrated RC topology simplifies board layout compared to discrete components. Verify that the specific resistance and capacitance values meet the cutoff frequency requirements of the application. Consider the thermal performance of the UFDFN package for the operating environment.
Part Context
This component belongs to the IP4264CZ8 series of integrated filters from NXP Semiconductors. The series includes variants with different resistance values, such as the IP4264CZ8-20-TTL and IP4264CZ8-40-TTL. These devices are designed to replace multiple discrete components, reducing assembly complexity and improving signal integrity in portable electronic devices.
Replacement Considerations
Direct substitutes include IP4264CZ8-20-TTL and IP4264CZ8-40-TTL from the same family. Verify that the resistance values of the alternative part align with the circuit's impedance and filtering requirements. Ensure the package type remains compatible with existing PCB footprints.
