IQ-0242H2

Power Line Filter Modules Overview

The DIT IQ-0242H2 is a single-phase EMC/EMI line filter module designed for power line applications. It features an IEC 320-C14 inlet connector and supports a current rating of 2 A with voltage ratings of 250 VAC at 50 to 60 Hz. The component utilizes a single-stage filtering architecture and employs quick connect terminals for circuit integration.

Power Line Filter Modules Feature Summary

• Single-phase EMI/EMC filtering capability
• IEC 320-C14 inlet connector interface
• Quick connect terminal configuration

Power Line Filter Modules Applications

• Power supply input filtering
• Electronic equipment noise suppression
• Compliance with electromagnetic interference standards

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version from DIT to confirm electrical characteristics and mechanical dimensions. Ensure the IEC 320-C14 mating connector compatibility with the target PCB or cable assembly. Check regulatory compliance documentation for intended market requirements before finalizing procurement.

Power Line Filter Modules Selection Notes

Select this component for applications requiring single-stage EMI suppression in single-phase AC circuits. Consider the 2 A current rating and 250 VAC voltage limit when designing the power stage. Verify that the quick connect termination style aligns with the system's wiring harness or board layout constraints.

Power Line Filter Modules Part Context

This part belongs to the IQ series of power line filters manufactured by DIT. These modules are engineered to attenuate conducted electromagnetic interference in AC power lines. The series typically offers standardized form factors compatible with common IEC inlet connectors.

Power Line Filter Modules Replacement Considerations

Cross-reference with IS-0242H2 for potential functional equivalents within the same manufacturer portfolio. Verify pinout, current ratings, and physical dimensions before substitution.
