IR-0222H

Power Line Filter Modules Overview

The IR-0222H is a single-phase EMC/EMI line filter module manufactured by DIT. It supports a current rating of 2 A and operates at voltages up to 250 V AC or DC. The unit is designed for 50 to 60 Hz frequencies and utilizes a single-stage filtering architecture. The component features an IEC 320-C14 inlet connector and quick connect terminals for circuit integration.

Power Line Filter Modules Feature Summary

• Incorporates an integrated fuse holder within the inlet filter design
• Utilizes a metal case construction to provide effective electromagnetic shielding
• Complies with over voltage category II standards per IEC 60664

Power Line Filter Modules Applications

• Single-phase power line noise suppression
• EMC/EMI mitigation in electronic equipment
• Industrial control system power inputs

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version from Dong Il Technology Ltd. to confirm exact electrical tolerances and mechanical dimensions. Ensure compatibility with IEC 320-C14 mating connectors and quick connect terminal specifications before integration into final assemblies.

Power Line Filter Modules Selection Notes

Select this component for applications requiring single-stage filtering with integrated fusing. The metal enclosure provides necessary shielding, while compliance with IEC 60950 ensures suitability for standard information technology equipment power interfaces.

Power Line Filter Modules Part Context

This model belongs to the IR series of power line filter modules produced by Dong Il Technology Ltd. under the DIT brand. It serves as a specialized solution for managing conducted interference in single-phase AC and DC power distribution networks.

Power Line Filter Modules Replacement Considerations

Cross-reference with other single-phase EMI filters featuring IEC 320-C14 inputs and 2A ratings. Verify that substitute components meet identical IEC 60950 compliance and include comparable shielding characteristics.
