IR2-N02CDH

Power Line Filter Modules Overview

The IR2-N02CDH is a single-phase EMC/EMI line filter module manufactured by DIT. It is rated for 2 A current and 250 V voltage, operating at 50 to 60 Hz. The unit features a single-stage design and utilizes an IEC 320-C14 inlet connector with quick connect terminals.

Power Line Filter Modules Feature Summary

• Single-phase EMC/EMI filtering
• IEC 320-C14 inlet interface
• Quick connect terminal style

Power Line Filter Modules Applications

• Power line noise suppression
• Electronic equipment input stages
• EMC compliance integration

Power Line Filter Modules Procurement Notes

Verify the exact suffix configuration against the manufacturer's official datasheet to ensure compatibility with specific voltage and current requirements. Confirm that the IEC 320-C14 inlet matches the mating connector on the target system. Ensure the quick connect terminals align with the wiring harness specifications before finalizing procurement.

Power Line Filter Modules Selection Notes

Select this component when a single-stage solution is sufficient for the required attenuation levels. Ensure the 2 A rating meets the maximum load current of the application. Verify that the physical dimensions of the module fit within the available enclosure space alongside the IEC inlet.

Power Line Filter Modules Part Context

This part belongs to the IR2 series of power line filters from DIT. The series includes variants with different current ratings and configurations. The IR2-N02CDH specifically addresses basic EMI/RFI suppression needs for low-power AC applications using standard IEC connectors.

Power Line Filter Modules Replacement Considerations

Check for direct substitutes within the IR2 series or equivalent modules from other manufacturers offering identical IEC 320-C14 interfaces and 2 A ratings. Ensure any replacement maintains the same single-stage filtering topology and terminal connection type.
