IR2-N04C2H

Power Line Filter Modules Overview

The IR2-N04C2H is a single-phase EMC/EMI line filter module manufactured by DIT. It features a rated current of 4 A and operates at voltages up to 250 V AC. The device supports frequencies between 50 Hz and 60 Hz and utilizes a single-stage filtering configuration. Electrical connections are established via quick connect terminals, while the mechanical interface employs an IEC 320-C14 inlet standard.

Power Line Filter Modules Feature Summary

• Single-stage electromagnetic interference suppression for single-phase power lines
• IEC 320-C14 connector interface for standardized equipment integration
• Quick connect terminal design for simplified circuit board mounting

Power Line Filter Modules Applications

• Single-phase electronic equipment requiring EMI noise reduction
• Power supply input stages in consumer or industrial devices
• Equipment compliant with IEC 320-C14 inlet standards

Power Line Filter Modules Procurement Notes

Verify that the required current rating of 4 A meets the specific application load requirements. Confirm compatibility with the 250 V AC voltage range and 50-60 Hz frequency spectrum. Ensure the quick connect terminal type matches the existing PCB footprint and that the IEC 320-C14 inlet aligns with the chassis opening dimensions before procurement.

Power Line Filter Modules Selection Notes

Select this component when a compact, single-stage solution is sufficient for low-current applications. The 4 A rating limits suitability for higher power loads. Consider the quick connect termination method against soldering requirements. Verify that the single-phase architecture matches the system's power distribution needs rather than three-phase alternatives.

Power Line Filter Modules Part Context

This module belongs to the IR2 series of power line filters from DIT. The series provides various current ratings and configurations for different electromagnetic compatibility requirements. The IR2-N04C2H specifically addresses lower current applications within this product family using standardized inlet interfaces.

Power Line Filter Modules Replacement Considerations

Cross-reference other IR2 series variants for different current ratings if the 4 A limit is insufficient. Verify that alternative single-stage filters maintain the same IEC 320-C14 mechanical interface and quick connect electrical termination to ensure physical and electrical compatibility without redesign.
