IR3-N06C2H

Power Line Filter Modules Overview

The IR3-N06C2H is a single-phase EMI/EMC line filter module manufactured by DONG IL TECHNOLOGY. It features an integrated double-pole power ON/OFF switch compliant with IEC 61058-1 standards. The unit utilizes a metal case to provide effective electromagnetic shielding and meets the overvoltage category II requirements of IEC 60664. Designed for panel mounting, it supports a current rating of 6 A at voltages up to 250 VAC/VDC within a 50–60 Hz frequency range.

Power Line Filter Modules Feature Summary

• Integrated double-pole power ON/OFF switch complying with IEC 61058-1
• Effective electromagnetic shielding provided by a metal case construction
• Compliance with overvoltage category II as defined by IEC 60664

Power Line Filter Modules Applications

• Single-phase power line filtering for electronic equipment
• Panel-mounted installations requiring integrated switching
• Applications demanding compliance with IEC 61058-1 switch standards

Power Line Filter Modules Procurement Notes

Verify that the required current rating of 6 A and voltage limit of 250 VAC/VDC align with your system specifications. Confirm that the panel mounting style and quick connect interface are compatible with your assembly design. Ensure the metal case shielding meets your enclosure's EMC requirements. Check that the IEC 60664 overvoltage category II classification satisfies your safety standards.

Power Line Filter Modules Selection Notes

Select this component when a combined filter and switch solution is needed for single-phase AC or DC lines. The 6 A rating suits moderate power applications. The metal housing offers superior shielding compared to plastic alternatives. Verify compatibility with IEC 320-C14 inlets if used as part of a larger connector system.

Power Line Filter Modules Part Context

This model belongs to the IR3 series of power line filter modules from DONG IL TECHNOLOGY. These units integrate filtering capabilities with mechanical switching functions. The series is designed for industrial and commercial electronics where space efficiency and EMC performance are critical. The specific suffix indicates the current rating and terminal configuration.

Power Line Filter Modules Replacement Considerations

Cross-reference with other single-phase EMI filters featuring integrated switches. Ensure replacement parts match the 6 A current rating and 250 VAC/VDC voltage limits. Verify that the new component also provides metal shielding and complies with IEC 61058-1 and IEC 60664 standards.
