IR3-N10CDH

Power Line Filter Modules Overview

The DIT IR3-N10CDH is a single-phase EMC/EMI line filter module designed for AC power applications. It supports a current rating of 10 A and operates at voltages up to 250 VAC or 250 VDC within the 50–60 Hz frequency range. The unit features an IEC 320-C14 inlet connector and utilizes quick-connect terminals for installation. Constructed with a metal case, it provides effective shielding and complies with IEC 61058-1 standards for the integrated double-pole power switch.

Power Line Filter Modules Feature Summary

• Integrated double-pole power ON/OFF switch compliant with IEC 61058-1
• Metal case construction providing effective electromagnetic shielding
• Meets overvoltage category II requirements per IEC 60664

Power Line Filter Modules Applications

• Industrial equipment requiring EMI suppression
• Medical devices needing certified power filtering
• Office automation systems with IEC inlet compatibility

Power Line Filter Modules Procurement Notes

Verify that the specific order matches the IR3-N10CDH designation to ensure correct voltage and current ratings. Confirm the presence of the IEC 320-C14 inlet and quick-connect terminal style during inspection. Ensure compliance with local safety regulations for installed equipment. Check for physical damage to the metal housing before integration into final assemblies.

Power Line Filter Modules Selection Notes

Select this component when a combined switching and filtering solution is required for single-phase AC lines. The 10 A rating suits moderate power loads, while the 250 VAC limit defines its operational boundary. The metal enclosure offers superior noise attenuation compared to plastic alternatives. Verify space constraints accommodate the module dimensions and terminal access requirements.

Power Line Filter Modules Part Context

This module belongs to the DIT IR3 series of power line filters. These components integrate filtering capabilities with mechanical switching functions. The series typically serves industries demanding high reliability and compact form factors. The IR3-N10CDH variant specifically denotes the 10 A current capacity and C14 inlet configuration within this product family.

Power Line Filter Modules Replacement Considerations

Direct substitutes must match the 10 A rating, 250 VAC specification, and IEC 320-C14 interface. Verify that alternative modules also include an integrated double-pole switch and metal shielding. Ensure replacement parts meet identical IEC 61058-1 and IEC 60664 standards for safety and performance equivalence.
