IR38164MTRPBFAUMA1

$4.90

Description：IC REG BUCK ADJ 30A 24PQFN
Series：-
Mfr：Infineon Technologies
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:7f2b37369d74 Category: Voltage Regulators - DC DC Switching Regulators Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IR38164MTRPBFAUMA1 is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists Infineon Technologies. Its product description is IC REG BUCK ADJ 30A 24PQFN. Review the specifications below when checking this part for your BOM.

Voltage Regulators - DC DC Switching Regulators specifications for IR38164MTRPBFAUMA1

Description：IC REG BUCK ADJ 30A 24PQFN
Series：-
Mfr：Infineon Technologies
Package：Tape & Reel (TR),Cut Tape (CT)
Function：Step-Down
Output Configuration：Positive
Topology：Buck
Output Type：Adjustable
Number of Outputs：1
Voltage - Input (Min)：1.5V
Voltage - Input (Max)：16V
Voltage - Output (Min/Fixed)：0.5V
Voltage - Output (Max)：14V
Current - Output：30A
Frequency - Switching：500kHz ~ 1.5MHz
Synchronous Rectifier：Yes
Operating Temperature：-40°C ~ 125°C (TJ)
Mounting Type：Surface Mount
Package / Case：24-PowerVFQFN
Supplier Device Package：24-PQFN (5x7)
Grade：-
Qualification：-

Voltage Regulators - DC DC Switching Regulators datasheet and documents for IR38164MTRPBFAUMA1

IR38164MTRPBFAUMA1

Voltage Regulators - DC DC Switching Regulators Overview

The IR38164MTRPBFAUMA1 is a single-phase synchronous buck regulator from Infineon’s OptiMOS IPOL series, designed for point-of-load applications. It operates with an input voltage range of 1.5 V to 16 V and delivers up to 30 A output current. The adjustable output voltage spans from 500 mV to 14 V. The device supports switching frequencies between 500 kHz and 1.5 MHz and functions within a junction temperature range of -40 °C to +125 °C. It utilizes a 34-lead QFN package.

Voltage Regulators - DC DC Switching Regulators Feature Summary

Integrates SVID digital interface for programmable voltage control
Employs fast constant on-time (COT) control architecture
Includes integrated overvoltage protection mechanisms

Voltage Regulators - DC DC Switching Regulators Applications

Server and storage system power distribution
Telecommunications base station equipment
Industrial automation controllers

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify component authenticity through authorized distributors due to end-of-life status. Confirm RoHS3 compliance and REACH SVHC declarations prior to integration. Validate moisture sensitivity level handling procedures during assembly to prevent package damage.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component for high-current single-phase requirements requiring digital voltage tracking. Ensure input supply stability within the specified 1.5 V to 16 V window. Verify thermal management capabilities match the 34-PQFN package constraints for the target operating environment.

Voltage Regulators - DC DC Switching Regulators Part Context

This part belongs to the IR38x6x family of OptiMOS IPOL converters. It shares architectural similarities with the IR38163 and IR38165 models but is distinguished by its specific SVID interface configuration and 30 A current rating profile within the synchronous buck topology.
