IRDM982-025MBTR

Overview

The IRDM982-025MBTR is a fully integrated motor driver IC from Infineon Technologies, designed for high-performance applications. It features a half-bridge output configuration with three independent channels, supporting parallel interface control. The device operates within a supply voltage range of 13.5V to 16.5V and is housed in a compact 40-PQFN (12x12 mm) package. This integration combines control logic and power stages into a single component.

Feature Summary

• Fully integrated design combining control logic and power stage
• Three-channel half-bridge output configuration
• Parallel interface for simplified system control

Applications

• Brushed DC motor control systems
• Industrial automation actuators
• Consumer appliance motor drives

Procurement Notes

Verify the specific suffix 'MBTR' against official Infineon documentation to confirm tape-and-reel packaging and temperature grade. Ensure compatibility with the 13.5V–16.5V operating range and 40-PQFN footprint during procurement planning.

Selection Notes

Select this component when a compact, multi-channel solution is required for brushed DC motors. The integrated nature reduces external component count compared to discrete gate drivers. Verify that the parallel interface meets the system's timing requirements.

Part Context

This part belongs to Infineon’s motor driver portfolio, specifically targeting applications requiring multiple half-bridge outputs in a small form factor. It serves as a complete solution for driving loads without separate logic and power stages.

Replacement Considerations

Consult official Infineon substitution guides for direct equivalents. Cross-reference pinouts and electrical characteristics carefully if considering alternative manufacturers.

FAQ

What is the output configuration of the IRDM982-025MBTR?

It features a half-bridge configuration with three independent outputs.

What is the recommended supply voltage range?

The device operates within a supply voltage range of 13.5V to 16.5V.
