IRSM836-035MB

Overview

The IRSM836-035MB is a three-phase intelligent power module from the CIPOS Nano family, designed for industrial applications. It features MOSFET switching devices with a 500 V voltage rating and a maximum on-resistance of 2.2 Ω at Tj = 25°C. The module supports a rated current of 3 A and delivers a mechanical power output of 70 W at 10 kHz. It utilizes a common source topology and does not include an internal NTC sensor.

Feature Summary

• Integrates three-phase MOSFETs within a compact CIPOS Nano package
• Provides high power density with 70 W mechanical power output capability
• Features low on-resistance for efficient power conversion

Applications

• Industrial motor drives
• Variable speed drive systems
• Pump control applications

Procurement Notes

Verify the specific suffix MB against official Infineon documentation to confirm pinout and thermal characteristics. Ensure compatibility with existing PCB footprints and gate driver interfaces before integration. Confirm that the industrial quality grade meets the operational requirements of the target environment.

Selection Notes

Select this module for applications requiring a 500 V rating and 3 A current capacity. Consider the 2.2 Ω on-resistance for thermal management planning. Evaluate the absence of an internal NTC against system temperature monitoring needs. Compare against other CIPOS Nano variants for size and performance trade-offs.

Part Context

This component belongs to the CIPOS Nano series, which offers integrated power modules for small home appliances and industrial uses. The IRSM836 series provides a balance of power density and ease of integration. It serves as a complete inverter stage solution, simplifying design complexity compared to discrete components.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
