IS43DR16640B-25DBLI-TR

$5.19

Description：IC DRAM 1GBIT PARALLEL 84TWBGA
Series：-
Mfr：ISSI, Integrated Silicon Solution Inc
Package：Tape & Reel (TR)

SKU:5ad3e112c1ee Category: Memory IC Brand: ISSI, Integrated Silicon Solution Inc

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IS43DR16640B-25DBLI-TR is listed in the Memory IC range at ChipApex. The manufacturer field lists ISSI, Integrated Silicon Solution Inc. Its product description is IC DRAM 1GBIT PARALLEL 84TWBGA. Review the specifications below when checking this part for your BOM.

Memory IC specifications for IS43DR16640B-25DBLI-TR

Description：IC DRAM 1GBIT PARALLEL 84TWBGA
Series：-
Mfr：ISSI, Integrated Silicon Solution Inc
Package：Tape & Reel (TR)
Memory Type：Volatile
Memory Format：DRAM
Technology：SDRAM - DDR2
Memory Size：1Gbit
Memory Organization：64M x 16
Memory Interface：Parallel
Clock Frequency：400 MHz
Write Cycle Time - Word, Page：15ns
Voltage - Supply：1.7V ~ 1.9V
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：84-TFBGA
Supplier Device Package：84-TWBGA (8x12.5)
Access Time：400 ps
Grade：-
Qualification：-

Memory IC datasheet and documents for IS43DR16640B-25DBLI-TR

IS43DR16640B-25DBLI-TR

Memory IC Overview

The IS43DR16640B-25DBLI-TR is a 1Gb (64M x 16) DDR2 SDRAM manufactured by ISSI. It features an 84-ball TW-BGA package and supports clock frequencies up to 400MHz with a 1.8V supply voltage. The device includes eight internal banks, a 4-bit prefetch architecture, and programmable CAS latencies ranging from 3 to 7. Key specifications include SSTL_1.8 interface compatibility, On-Die Termination (ODT), and support for Partial Array Self Refresh (PASR).

Memory IC Feature Summary

Supports concurrent operations across eight internal banks.
Features a 4-bit prefetch architecture for high-speed data transfer.
Includes On-Die Termination (ODT) for signal integrity.
Offers Partial Array Self Refresh (PASR) for power management.

Memory IC Applications

General-purpose memory systems requiring DDR2 SDRAM.
Embedded applications utilizing the 84-ball TW-BGA form factor.
Industrial environments supporting specified temperature ranges.

Memory IC Procurement Notes

Verify that the ordering suffix '-TR' corresponds to tape-and-reel packaging as indicated by distributor listings. Confirm the specific speed grade matches system timing requirements. Ensure the component meets RoHS compliance standards required for your assembly process. Cross-reference the manufacturer part number with official datasheets to validate electrical characteristics before finalizing procurement.

Memory IC Selection Notes

Select this component when a 1Gb density with a 16-bit data bus width is required. The 84-ball TW-BGA package is suitable for space-constrained designs. Consider the 400MHz maximum frequency and 1.8V operating voltage for power and performance alignment. Verify that the industrial or automotive temperature grades meet environmental constraints.

Memory IC Part Context

This part belongs to the IS43/46DR16640B series of 1Gb DDR2 SDRAMs. It shares architectural similarities with other members of the family but differs in organization, package type, and specific speed grades. The 'IS43' prefix typically denotes commercial or industrial grade devices, while the 'B' indicates the specific revision or feature set within the DDR2 product line.
