IS45S16100C1-7TLA1-TR is listed in the Memory IC range at ChipApex. The manufacturer field lists ISSI, Integrated Silicon Solution Inc. Its product description is IC DRAM 16MBIT PAR 50TSOP II. Review the specifications below when checking this part for your BOM.
Memory IC specifications for IS45S16100C1-7TLA1-TR
- Description：IC DRAM 16MBIT PAR 50TSOP II
- Series：-
- Mfr：ISSI, Integrated Silicon Solution Inc
- Package：Tape & Reel (TR)
- Memory Type：Volatile
- Memory Format：DRAM
- Technology：SDRAM
- Memory Size：16Mbit
- Memory Organization：1M x 16
- Memory Interface：Parallel
- Clock Frequency：143 MHz
- Write Cycle Time - Word, Page：-
- Voltage - Supply：3V ~ 3.6V
- Operating Temperature：-40°C ~ 85°C (TA)
- Mounting Type：Surface Mount
- Package / Case：50-TSOP (0.400", 10.16mm Width)
- Supplier Device Package：50-TSOP II
- Access Time：5.5 ns
- Grade：-
- Qualification：-
Memory IC datasheet and documents for IS45S16100C1-7TLA1-TR
Memory IC Overview
The IS45S16100C1-7TLA1-TR is a 16-Mbit Synchronous DRAM manufactured by ISSI. It features a 16-bit data bus width and supports a maximum clock frequency of 143 MHz. The device is organized as 524,288 words by 16 bits across two independent banks. It operates on a single 3.3V power supply with an LVTTL interface. Available in automotive temperature ranges (Option A: 0°C to +70°C; Option A1: -40°C to +85°C), it utilizes a 50-pin TSOP-II or 60-ball fBGA package.
Memory IC Feature Summary
- Dual internal bank architecture allowing simultaneous and independent operation
- Fully synchronous pipeline design with all signals referenced to the positive clock edge
- Configurable burst lengths including sequential and interleave sequences
- Supports programmable CAS latency for optimized timing control
Memory IC Applications
- Automotive electronic systems requiring extended temperature stability
- High-speed data buffering in embedded controllers
- Graphics memory subsystems utilizing parallel interfaces
- Industrial control units needing reliable volatile storage
Memory IC Procurement Notes
Verify the specific suffix code against the manufacturer's current datasheet to confirm the exact operating temperature range and package type. Ensure that the ordering suffix matches the required thermal grade and physical footprint for your PCB layout. Confirm RoHS compliance status directly with the supplier documentation prior to finalizing procurement orders.
Memory IC Selection Notes
Select this component when a high-density 16-bit parallel interface is required within automotive thermal constraints. Evaluate the dual-bank capability for applications demanding concurrent access operations. Consider the available package options based on board space limitations and ensure the system voltage aligns with the specified 3.3V requirement.
Memory IC Part Context
This part belongs to the IS45S16100 series of Synchronous DRAMs from Integrated Silicon Solution Inc. The series provides scalable memory solutions for various industrial and automotive applications. The C1 variant specifically denotes the generation supporting the described pinout and electrical characteristics defined in the Rev C specification.
Memory IC Replacement Considerations
Direct substitutes include other ISSI parts within the IS45S16100 family sharing identical pinouts and electrical specifications. Verify compatibility regarding the specific temperature grade and package style before substitution.
