ISC0324S12-TR

ISC0324S12-TR is listed in the DC DC Converters range at ChipApex. The manufacturer field lists XP Power. Its product description is DC DC CONVERTER 12V 3W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for ISC0324S12-TR

• Description：DC DC CONVERTER 12V 3W
• Series：ISC03 (3W)
• Mfr：XP Power
• Package：Tape & Reel (TR),Cut Tape (CT),Bulk
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：12V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：250mA
• Power (Watts)：3 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：Remote On/Off, OCP, SCP, UVLO
• Operating Temperature：-40°C ~ 100°C (With Derating)
• Efficiency：80%
• Mounting Type：Surface Mount
• Package / Case：16-SMD Module, 7 Leads
• Size / Dimension：0.94" L x 0.54" W x 0.32" H (24.0mm x 13.7mm x 8.3mm)
• Supplier Device Package：-
• Control Features：Enable, Active High
• Approval Agency：CE, UKCA, UL
• Standard Number：60950-1; 62368-1
• Grade：-
• Qualification：-
