ISL9113ERAZ-T is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists Renesas Electronics Corporation. Its product description is IC REG BOOST ADJ 1.1A 8DFN. Review the specifications below when checking this part for your BOM.
Voltage Regulators - DC DC Switching Regulators specifications for ISL9113ERAZ-T
- Description：IC REG BOOST ADJ 1.1A 8DFN
- Series：-
- Mfr：Renesas Electronics Corporation
- Package：Tape & Reel (TR),Cut Tape (CT)
- Function：Step-Up
- Output Configuration：Positive
- Topology：Boost
- Output Type：Adjustable
- Number of Outputs：1
- Voltage - Input (Min)：0.8V
- Voltage - Input (Max)：4.7V
- Voltage - Output (Min/Fixed)：3V
- Voltage - Output (Max)：5.2V
- Current - Output：1.1A (Switch)
- Frequency - Switching：1.8MHz
- Synchronous Rectifier：Yes
- Operating Temperature：-20°C ~ 85°C (TA)
- Mounting Type：Surface Mount
- Package / Case：8-VFDFN Exposed Pad
- Supplier Device Package：8-DFN (2x2)
- Grade：-
- Qualification：-
Voltage Regulators - DC DC Switching Regulators datasheet and documents for ISL9113ERAZ-T
Voltage Regulators - DC DC Switching Regulators Overview
The ISL9113ERAZ-T is a boost switching voltage regulator manufactured by Renesas Electronics Corporation. It operates in surface-mount DFN-8 packages and delivers up to 500 mA output current with an adjustable output voltage range of 1 V to 5.2 V. The device functions at a fixed switching frequency of 1.8 MHz and maintains a low quiescent current of 20 µA. It supports minimum operating temperatures of -20°C.
Voltage Regulators - DC DC Switching Regulators Feature Summary
- Boost topology for step-up voltage conversion
- Integrated synchronous rectification
- Low quiescent current operation
Voltage Regulators - DC DC Switching Regulators Applications
- Portable electronic devices requiring battery voltage boosting
- Embedded systems with single-cell lithium-ion power sources
- Industrial control modules needing regulated supply rails
Voltage Regulators - DC DC Switching Regulators Procurement Notes
Verify the specific suffix 'ERAZ' against official Renesas documentation to confirm package type and tape-and-reel specifications. Ensure compatibility with your PCB footprint, as DFN-8 dimensions are critical. Cross-reference RoHS compliance status directly from the manufacturer's datasheet before finalizing procurement orders.
Voltage Regulators - DC DC Switching Regulators Selection Notes
Select this component when a compact boost converter is required for low-power applications. The 1.8 MHz frequency allows for smaller passive components compared to lower-frequency alternatives. Verify that the input voltage range aligns with your source, and ensure the 500 mA output capability meets the load requirements without exceeding thermal limits in the DFN-8 package.
Voltage Regulators - DC DC Switching Regulators Part Context
This part belongs to the ISL9113 family of high-efficiency DC-DC converters. It is designed for space-constrained portable electronics. The series offers various package options and temperature grades. Renesas acquired Intersil, which originally developed this line, ensuring continued support and integration into broader power management portfolios.
Voltage Regulators - DC DC Switching Regulators Replacement Considerations
Check for ISL9113 variants with different suffixes for package or temperature changes. Direct substitutes may include other Renesas boost regulators with similar current ratings. Verify pinout compatibility before replacing.
