JAH0212D12 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists XP Power. Its product description is DC DC CONVERTER +/-12V 2W. Review the specifications below when checking this part for your BOM.
DC DC Converters specifications for JAH0212D12
- Description：DC DC CONVERTER +/-12V 2W
- Series：JAH (2W)
- Mfr：XP Power
- Package：Tube
- Type：Isolated Module
- Number of Outputs：2
- Voltage - Input (Min)：10.8V
- Voltage - Input (Max)：13.2V
- Voltage - Output 1：12V
- Voltage - Output 2：-12V
- Voltage - Output 3：-
- Voltage - Output 4：-
- Current - Output (Max)：83mA
- Power (Watts)：2 W
- Voltage - Isolation：1 kV
- Applications：ITE (Commercial)
- Features：SCP, UVLO
- Operating Temperature：-40°C ~ 100°C
- Efficiency：78%
- Mounting Type：Through Hole
- Package / Case：24-DIP Module, 12 Leads
- Size / Dimension：1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
- Supplier Device Package：-
- Control Features：-
- Approval Agency：-
- Standard Number：-
- Grade：-
- Qualification：-
DC DC Converters datasheet and documents for JAH0212D12
