JCW015

Overview

The JCW015 is a linearly polarized, straight whip RF antenna designed for Wi-Fi applications. It operates within the 2400 to 2483.5 MHz frequency range with an 83.5 MHz bandwidth. The component provides a gain of 2 dBi at zenith and maintains a VSWR of 2. It features an RP-SMA male connector for installation and has a maximum height of 53.70 mm.

Feature Summary

• Straight whip design optimized for Wi-Fi signal transmission
• Linear polarization for consistent directional performance
• RP-SMA male connector interface for secure mounting

Applications

• Wi-Fi network infrastructure equipment
• Wireless access point installations
• IoT devices requiring 2.4 GHz connectivity

Procurement Notes

Verify the specific connector type and polarity against system requirements before integration. Confirm that the operating frequency range aligns with local regulatory standards for wireless communications. Ensure mechanical clearance accommodates the specified maximum height during assembly planning.

Selection Notes

Select this model when a compact, fixed-gain solution is required for standard Wi-Fi bands. The straight whip form factor suits vertical mounting orientations. Consider the RP-SMA interface compatibility with existing cable assemblies and device ports to ensure seamless integration without additional adapters.

Part Context

JC Antenna manufactures specialized RF components including GPS, GLONASS, and communication antennas. The JCW015 belongs to their Wi-Fi antenna portfolio, targeting IoT and general wireless connectivity markets. The company emphasizes custom solutions alongside standard product lines for global distribution.

Replacement Considerations

No public substitute part numbers are documented for this specific model.
