KA1-MH10205M4

$64.27

Description：2P M KONA RA PCB BRD AND PNL MNT
Series：KONA
Mfr：Harwin Inc.
Package：Tube

SKU:58bb8537b21f Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：2P M KONA RA PCB BRD AND PNL MNT
Series：KONA
Mfr：Harwin Inc.
Package：Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.335" (8.50mm)
Number of Positions：2
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Panel Mount, Through Hole, Right Angle
Termination：Solder
Fastening Type：Threaded
Contact Length - Mating：-
Contact Length - Post：0.144" (3.66mm)
Overall Contact Length：-
Insulation Height：0.429" (10.90mm)
Contact Shape：Circular
Contact Finish - Mating：-
Contact Finish Thickness - Mating：-
Contact Finish - Post：-
Contact Material：-
Insulation Material：-
Features：Mounting Flange
Operating Temperature：-
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：-
Current Rating (Amps)：-
Voltage Rating：-

Download product information

KA1-MH10205M4

Overview

The KA1-MH10205M4 is a male pin header from the Kona series, designed for panel and through-hole mounting. It features a 2-position configuration with an 8.5 mm pitch. The connector utilizes a right-angle installation style with solder pin termination. Constructed with phosphor bronze contacts plated in gold, it supports a continuous current rating of 60 A per contact. The housing material is polyamide, rated UL 94 V-0 for flammability.

Feature Summary

High-current capability supporting up to 60 A per contact
Integrated metal backshell for robust panel mounting
Right-angle through-hole design for space-efficient board integration

Applications

Power distribution in extreme conditions
General purpose industrial connections
High reliability power systems

Procurement Notes

Verify the specific suffix M4 corresponds to the required metal backshell configuration. Confirm that the 8.5 mm pitch aligns with the target panel cutout dimensions. Ensure the 60 A rating meets the thermal requirements of the application environment. Check RoHS compliance status if restricted substances are a constraint.

Selection Notes

Select this component when high current density is required in a compact form factor. The integrated backshell simplifies assembly by providing a secure panel mount interface. Consider the right-angle orientation for optimal cable routing relative to the PCB plane. Validate that the 2-position count matches the circuit requirements.

Part Context

This part belongs to the Harwin Kona series, which focuses on maximizing power in demanding environments. The series is characterized by its ability to handle significant current loads while maintaining structural integrity. The KA1 variant specifically denotes the horizontal panel mount configuration with a metal backshell.
