KA1-MV20305M2

$36.09

Description：3 POS. MALE SIL VERTICAL THROUGH
Series：KONA
Mfr：Harwin Inc.
Package：Tube

SKU:9d2d071a533f Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：3 POS. MALE SIL VERTICAL THROUGH
Series：KONA
Mfr：Harwin Inc.
Package：Tube
Connector Type：Header
Contact Type：Male Pin, Power
Pitch - Mating：0.335" (8.50mm)
Number of Positions：3
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Threaded
Contact Length - Mating：-
Contact Length - Post：0.232" (5.90mm)
Overall Contact Length：-
Insulation Height：0.374" (9.50mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：-
Contact Finish - Post：Gold
Contact Material：Beryllium Copper
Insulation Material：Polyphenylene Sulfide (PPS)
Features：Pick and Place
Operating Temperature：-65°C ~ 150°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：60A per Contact
Voltage Rating：-

Download product information

KA1-MV20305M2

Overview

The KA1-MV20305M2 is a rectangular power connector from the KONA KA1 series by Harwin Inc. It features a 3-position male pin configuration designed for vertical through-hole PCB mounting. The connector supports a current rating of 60A per contact and operates within a temperature range of -55°C to +125°C. The housing is constructed from black UL94 V-0 rated material, ensuring fire resistance. This component is part of the high-reliability Power to the Board solution, offering robust performance for demanding electrical applications.

Feature Summary

High current capacity with 60A rating per contact
Vertical through-hole mounting for secure PCB integration
UL94 V-0 flammability rating for enhanced safety

Applications

Industrial power distribution systems
High-current board-to-board connections
Power supply unit internal wiring

Procurement Notes

Verify that the specific KA1-MV20305M2 designation matches the required 3-position vertical through-hole specification. Confirm that the 60A per contact current rating aligns with the system's thermal management capabilities. Ensure the black UL94 V-0 housing material meets environmental compliance requirements for the intended deployment environment.

Selection Notes

Select this component when a high-current, vertically oriented connection is required on a printed circuit board. The 8.5mm pitch and 3-position layout suit compact power modules. Consider the through-hole termination method for mechanical stability in vibration-prone environments where surface mount alternatives may be insufficient.

Part Context

This part belongs to the KONA KA1 series, a line of high-reliability connectors designed for power applications. The series is known for its ability to handle significant current loads while maintaining compact form factors. The KA1-MV20305M2 specifically addresses needs for vertical orientation and through-hole assembly in power-intensive electronic designs.
