KA1-MV20405M1

Overview

The KA1-MV20405M1 is a male pin header connector from the Harwin Kona KA1 series, designed for high-reliability power applications. It features a 4-position configuration with an 8.50 mm (0.335 inch) pitch spacing. The component utilizes a straight through-hole mounting style and accepts screw-lock cable housing mating options. Rated for 60 A current and 1.5 kV voltage, it supports robust electrical performance in demanding environments.

Feature Summary

• High current and voltage rating suitable for power distribution
• Screw-lock mechanism ensures secure cable retention
• Robust construction for high-reliability industrial use

Applications

• Industrial power supply connections
• High-voltage equipment interconnects
• Heavy-duty machinery control panels

Procurement Notes

Verify that the specific part number KA1-MV20405M1 matches the required 4-position count and 8.50 mm pitch before ordering. Confirm compatibility with the corresponding female socket or cable housing assembly to ensure proper mechanical engagement and electrical continuity. Check technical documentation for any specific handling or storage requirements related to the screw-lock feature.

Selection Notes

Select this connector when high current capacity of 60 A and high voltage isolation of 1.5 kV are required. The 8.50 mm pitch provides ample spacing for safety clearance. Ensure the application environment supports the through-hole mounting method and that the screw-lock interface aligns with the system's cable management strategy.

Part Context

This component belongs to the Kona KA1 series by Harwin Inc., which specializes in rectangular power connectors. The series is engineered for high-reliability applications requiring secure connections and significant current carrying capabilities. The KA1 series typically features robust housings and precise contact alignment for consistent performance.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
