KBA-40+

Overview

The KBA-40+ is a surface-mount frequency multiplier module manufactured by Mini-Circuits. It operates as a 2X multiplier with an output frequency range of 5400 MHz to 9600 MHz. The component is designed for RF and microwave applications, providing signal frequency extension capabilities within this specified band.

Feature Summary

• Surface-mount technology implementation
• Frequency multiplication functionality
• Broadband output operation

Applications

• RF systems
• Microwave systems
• Signal frequency extension

Procurement Notes

Verify the specific datasheet version prior to procurement, as conflicting documentation exists regarding the exact classification of this part number. Confirm that the intended application aligns with the 5400 MHz to 9600 MHz output frequency range. Ensure compatibility with surface-mount assembly processes. Cross-reference the manufacturer's official specifications to resolve any discrepancies in product description found across different distributor platforms.

Selection Notes

Select this component when a compact surface-mount solution is required for doubling input frequencies into the 5.4 GHz to 9.6 GHz range. Consider the physical footprint constraints of the design. Evaluate thermal management requirements associated with surface-mount power dissipation. Verify that the input drive levels match the multiplier's operational specifications for optimal performance.

Part Context

Mini-Circuits is a global leader in the design and manufacturing of RF, IF, and microwave components operating from DC to 86 GHz. The company provides a wide range of passive and active components for various communication and industrial applications. This module represents their surface-mount product line focused on frequency conversion tasks.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided data.
