Product Detailed Parameters
- Description：BRIDGE RECT 1PHASE 50V 3A KBP
- Series：-
- Mfr：SMC Diode Solutions
- Package：Tube
- Diode Type：Single Phase
- Technology：Standard
- Voltage - Peak Reverse (Max)：50 V
- Current - Average Rectified (Io)：3:00 AM
- Voltage - Forward (Vf) (Max) @ If：1.1 V @ 3 A
- Current - Reverse Leakage @ Vr：5 µA @ 50 V
- Operating Temperature：-55°C ~ 150°C (TJ)
- Mounting Type：Through Hole
- Package / Case：4-ESIP
- Supplier Device Package：KBP
- Grade：-
- Qualification：-
Download product information
Overview
The KBP3005G is a single-phase bridge rectifier manufactured by SMC Diode Solutions. It features a maximum repetitive peak reverse voltage of 50 V and an average forward rectified current rating of 3 A. The device utilizes standard recovery technology with a maximum non-repetitive peak surge current capability of 100 A at a single half-sine wave. Forward voltage drop is specified at 1.1 V when conducting 3 A. The component operates within a junction temperature range of -55°C to +150°C and is housed in a KBP surface-mount package.
Feature Summary
- Single-phase bridge rectifier configuration for AC-to-DC conversion
- Surface-mount KBP package design for automated assembly
- High thermal stability supporting extended operating temperatures
Applications
- General-purpose AC/DC power supply circuits
- Battery charging systems
- Low-voltage DC power adapters
Procurement Notes
Verify the specific suffix designation against the manufacturer's official datasheet to confirm exact electrical tolerances and packaging variations. Confirm RoHS compliance status and REACH registration details prior to integration. Ensure the procurement source provides valid traceability documentation for quality assurance purposes.
Selection Notes
Select this component for applications requiring low-voltage rectification with moderate current demands. The KBP form factor supports surface-mount technology, reducing board space requirements compared to through-hole alternatives. Verify that the 50 V reverse voltage rating exceeds the peak inverse voltage present in the target circuit under all operating conditions.
Part Context
The KBP3005G belongs to the KBP series of single-phase bridge rectifiers from SMC Diode Solutions. This series offers various voltage ratings and current capacities within a standardized surface-mount footprint. The KBP package allows for efficient PCB layout and is suitable for high-volume manufacturing environments requiring reliable rectification performance.
Replacement Considerations
Direct pin-compatible replacements must match the 50 V reverse voltage, 3 A current rating, and KBP package dimensions. Verify that substitute components maintain equivalent forward voltage characteristics and thermal resistance values to ensure circuit performance parity.
