KBPF304G

Overview

The KBPF304G is a bridge rectifier manufactured by Taiwan Semiconductor Corporation. It features a single-phase configuration with three elements and utilizes silicon as the semiconductor material. The device is housed in a plastic KBP package, specifically identified as ITO-207A, and contains three pins. Key electrical ratings include a maximum repetitive peak reverse voltage of 400 V and an average forward rectified current of 3 A. The component is designed for through-hole mounting and complies with RoHS standards.

Feature Summary

• Single-phase bridge rectifier configuration
• High surge current capability
• Epoxy meets UL 94 V-0 flammability rating

Applications

• General purpose power supply circuits
• DC output rectification
• Battery charging applications

Procurement Notes

Verify the manufacturer datasheet to confirm exact thermal resistance values and specific pinout configurations for the KBP package. Ensure that the selected variant matches the required voltage and current specifications for the target application environment. Cross-reference ordering information to identify any suffixes that may indicate packaging or compliance variations.

Selection Notes

Select this component based on its 400 V reverse voltage rating and 3 A continuous current capacity. Consider the thermal management requirements associated with the KBP plastic package. Verify compatibility with the PCB footprint for the ITO-207A housing. Ensure the operating temperature range aligns with the system's environmental constraints.

Part Context

This part belongs to the KBPF series of bridge rectifiers from Taiwan Semiconductor. The series offers various voltage ratings while maintaining a consistent 3 A current capability. These components are widely used in compact power supply designs where space efficiency and reliability are prioritized. The KBP package provides a robust solution for through-hole assembly processes.
