KNA16300C16MA7TS

Overview

The KNA16300C16MA7TS is an EMI/RFI filter array manufactured by KYOCERA AVX. It utilizes LC technology to provide low-pass filtering capabilities. The component features a four-channel configuration with a capacitance of 16 pF per channel and a voltage rating of 25 V. It has a cutoff frequency of 300 MHz and is housed in a compact 1.6 x 0.8 mm package.

Feature Summary

• Four-channel LC filter network for multi-line signal protection
• Low-pass filtering architecture designed for EMI suppression
• Compact surface-mount form factor suitable for dense layouts

Applications

• High-speed data line interference mitigation
• Portable electronic device signal integrity management
• Consumer electronics EMI reduction

Procurement Notes

Verify product status as this specific part number is listed as obsolete or no longer manufactured. Confirm availability through secondary market channels or authorized distributors holding remaining stock. Ensure the procurement source provides valid traceability documentation. Check for potential tariff implications if shipping to the United States, as costs may apply during transit.

Selection Notes

Select this component when a four-channel LC filter solution is required for signals up to 300 MHz. The 16 pF capacitance value suits applications needing minimal signal loading. Consider the 25 V rating against circuit operating voltages. Evaluate the small footprint requirements against available board space constraints.

Part Context

This component belongs to the KYOCERA AVX EMI/RFI filter arrays category. These devices are engineered to suppress electromagnetic interference in high-frequency circuits. The series typically offers integrated solutions for multiple lines within a single package, reducing assembly complexity compared to discrete components.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Due to the obsolete status, verify functional equivalence with current KYOCERA AVX filter arrays or alternative manufacturers offering similar LC topology specifications.
