KNH16C104DA5TS

Overview

The KYOCERA AVX KNH16C104DA5TS is a feed-through capacitor designed for surface-mount applications. It features a capacitance of 0.1 µF and a rated voltage of 25 V DC. The component supports a current rating of 2 A and utilizes a 0603 (1608 Metric) package with dimensions of 1.6 mm in length and 0.80 mm in width. Operating temperatures range from -40°C to 85°C.

Feature Summary

• Integrates LC filtering within a compact three-terminal surface-mount structure
• Supports high-speed signal transmission with a 2 A current rating
• Designed for EMI/RFI suppression in differential line circuits

Applications

• High-speed data line protection
• Differential signaling interfaces
• General-purpose EMI filtering

Procurement Notes

Verify the specific datasheet version for the KNH16C104DA5TS to confirm mechanical tolerances and soldering profiles. Ensure compatibility with the target PCB footprint, specifically the 0603 metric dimensions. Cross-reference electrical ratings against the circuit requirements to validate performance under operating conditions.

Selection Notes

Select this component for applications requiring integrated filtering on high-speed lines where space is limited. The three-terminal design offers superior high-frequency performance compared to standard two-terminal capacitors. Evaluate the 2 A current handling capability to ensure it meets the load requirements of the specific interface being protected.

Part Context

This part belongs to the KYOCERA AVX feed-through capacitor series, which combines filtering capabilities with signal integrity preservation. These components are engineered to minimize parasitic inductance, making them suitable for modern high-density electronics that demand effective noise suppression without compromising signal quality.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
