KO EELP41.22-Q1S2-25-A8J8-020-R18

$0.13

Description：LED ORANGE DIFFUSED 0603 SMD
Series：SMARTLED® 0603
Mfr：ams-OSRAM USA INC.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:3717a2dced59 Category: LED Indication - Discrete Brand: ams-OSRAM USA INC.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

KO EELP41.22-Q1S2-25-A8J8-020-R18 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists ams-OSRAM USA INC.. Its product description is LED ORANGE DIFFUSED 0603 SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for KO EELP41.22-Q1S2-25-A8J8-020-R18

Description：LED ORANGE DIFFUSED 0603 SMD
Series：SMARTLED® 0603
Mfr：ams-OSRAM USA INC.
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Orange
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Diffused
Millicandela Rating：175.5mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.16mm x 0.80mm
Voltage - Forward (Vf) (Typ)：2V
Current - Test：20mA
Viewing Angle：130°, 130°
Mounting Type：Surface Mount
Wavelength - Dominant：605nm
Wavelength - Peak：610nm
Features：-
Package / Case：0603 (1608 Metric)
Supplier Device Package：603
Size / Dimension：1.60mm L x 0.80mm W
Height (Max)：0.50mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for KO EELP41.22-Q1S2-25-A8J8-020-R18

KO EELP41.22-Q1S2-25-A8J8-020-R18

LED Indication - Discrete Overview

The KO EELP41.22-Q1S2-25-A8J8-020-R18 is a single-color orange surface-mount LED manufactured by ams OSRAM AG, part of the SMARTLED KR EELP41.22 series. It features a 0603 (1608 metric) package with dimensions of 1.60mm length, 0.80mm width, and a maximum height of 0.80mm. The device emits orange light at a peak wavelength of 610nm and a dominant wavelength of 605nm. Typical forward voltage is 2V at a test current of 20mA, producing an intensity of 162.5mcd. It has a 160-degree viewing angle, white diffused lens, and MSL level 2.

LED Indication - Discrete Feature Summary

Standard configuration with a rectangular lens featuring a flat top design
Diffused lens transparency for wide-angle light distribution
Compliant with ROHS3 specifications and REACH regulations

LED Indication - Discrete Applications

Electronic equipment status indicators
Instrument panel illumination
Consumer appliance signaling

LED Indication - Discrete Procurement Notes

Verify component authenticity through authorized channels due to end-of-life status. Confirm RoHS3 compliance and moisture sensitivity level 2 handling requirements during storage and assembly. Cross-reference datasheet revisions for any recent packaging or material changes before finalizing procurement orders.

LED Indication - Discrete Selection Notes

Select this component for applications requiring a standard orange indicator in a compact 0603 footprint. Ensure circuit design accommodates the 2V typical forward voltage and 20mA test current. Verify that the 160-degree viewing angle aligns with optical visibility requirements for the target enclosure.

LED Indication - Discrete Part Context

This component belongs to the SMARTLED KR EELP41.22 series, designed for general-purpose indication in space-constrained electronics. It shares physical dimensions with other 0603 LEDs but differs in color and intensity characteristics. The product line emphasizes standardized mounting profiles for automated surface-mount assembly processes.
