KU-11D45-12

KU-11D45-12 is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists TE Connectivity Potter & Brumfield Relays. Its product description is RELAY GEN PURPOSE DPDT 10A 12V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for KU-11D45-12

• Description：RELAY GEN PURPOSE DPDT 10A 12V
• Series：KU
• Mfr：TE Connectivity Potter & Brumfield Relays
• Package：Bulk
• Mounting Type：Chassis Mount
• Coil Voltage：12VDC
• Contact Form：DPDT (2 Form C)
• Contact Rating (Current)：10:00 AM
• Switching Voltage：240VAC - Max
• Load - Max Switching：-
• Coil Current：100 mA
• Coil Type：Non Latching
• Features：-
• Termination Style：Quick Connect - 0.187" (4.7mm)
• Seal Rating：-
• Coil Insulation：Class B
• Must Operate Voltage：9 VDC
• Must Release Voltage：-
• Operating Temperature：-45°C ~ 85°C
• Contact Material：Silver Cadmium Oxide (AgCdO)
• Approval Agency：CSA, UR
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：15 ms
• Release Time：10 ms

Power Relays, Over 2 Amps datasheet and documents for KU-11D45-12
