KW60-12S5

KW60-12S5 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Polytron. Its product description is DC DC CONVERTER 5V 60W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for KW60-12S5

• Description：DC DC CONVERTER 5V 60W
• Series：KW60 (60W)
• Mfr：Polytron
• Package：Bulk
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：18V
• Voltage - Output 1：5V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：12A
• Power (Watts)：60 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial)
• Features：Adjustable Output
• Operating Temperature：-25°C ~ 71°C
• Efficiency：86%
• Mounting Type：Through Hole
• Package / Case：14-DIP Module, 13 Leads
• Size / Dimension：5.51" L x 3.46" W x 1.34" H (140.0mm x 88.0mm x 34.0mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for KW60-12S5
