L233LYC-TR is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists American Opto Plus LED. Its product description is LED YELLOW CLEAR SMD R/A. Review the specifications below when checking this part for your BOM.
LED Indication - Discrete specifications for L233LYC-TR
- Description：LED YELLOW CLEAR SMD R/A
- Series：-
- Mfr：American Opto Plus LED
- Package：Bulk
- Color：Yellow
- Configuration：-
- Lens Color：Colorless
- Lens Transparency：Clear
- Millicandela Rating：800mcd
- Lens Style：Rectangle with Irregular Top
- Lens Size：-
- Voltage - Forward (Vf) (Typ)：2.2V
- Current - Test：20mA
- Viewing Angle：115°
- Mounting Type：Surface Mount, Right Angle
- Wavelength - Dominant：590nm
- Wavelength - Peak：-
- Features：-
- Package / Case：2-SMD, No Lead
- Supplier Device Package：SMD
- Size / Dimension：2.80mm L x 1.20mm W
- Height (Max)：0.90mm
- Grade：-
- Qualification：-
LED Indication - Discrete datasheet and documents for L233LYC-TR
LED Indication - Discrete Overview
The L233LYC-TR is a discrete surface-mount LED manufactured by American Opto Plus LED. It features a yellow illumination color with a peak wavelength of 590nm. The component delivers a luminous intensity of 800mcd and operates with a forward current of 20mA. It is designed for an operating temperature range of -40°C to +85°C.
LED Indication - Discrete Feature Summary
- Yellow illumination output
- Surface mount package configuration
- Discrete diode structure
LED Indication - Discrete Applications
- Panel indicator lighting
- Control unit status signaling
- Electronic equipment visual feedback
LED Indication - Discrete Procurement Notes
Verify the specific datasheet version from American Opto Plus LED to confirm exact binning classifications and forward voltage tolerances. Ensure compatibility with automated pick-and-place equipment regarding the tape and reel specifications. Confirm that the thermal management requirements align with the specified operating temperature range during final assembly processes.
LED Indication - Discrete Selection Notes
Select this component when a yellow discrete SMD LED is required for panel mounting applications. Consider the 800mcd intensity rating against ambient light conditions. Verify that the 20mA forward current specification matches the driving circuit capabilities. Check mechanical footprint constraints against the package dimensions provided in the official documentation.
LED Indication - Discrete Part Context
This part belongs to the American Opto Plus LED discrete indication series. It serves as a standard component for visual status indicators in electronic assemblies. The manufacturer produces various LED types including displays and lamps, with this model focusing on single-color indication tasks.
LED Indication - Discrete Replacement Considerations
Consult official cross-reference lists from American Opto Plus LED for verified substitutes. Ensure replacement parts match the 590nm wavelength and 800mcd intensity requirements. Verify identical package dimensions and pin configurations for direct board replacement.
