L301314A-151LHF

$8.33

Description：150uH, 43mOhm, 2.6A Max. Toroida
Series：L301314A
Mfr：ITG Electronics, Inc.
Package：Bulk

SKU:7ef093298c12 Category: Fixed Inductors Brand: ITG Electronics, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

L301314A-151LHF is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists ITG Electronics, Inc.. Its product description is 150uH, 43mOhm, 2.6A Max. Toroida. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for L301314A-151LHF

Description：150uH, 43mOhm, 2.6A Max. Toroida
Series：L301314A
Mfr：ITG Electronics, Inc.
Package：Bulk
Type：Toroidal
Material - Core：Alloy Powder
Inductance：150 µH
Tolerance：±15%
Current Rating (Amps)：6:00 AM
Current - Saturation (Isat)：2.6A
Shielding：Unshielded
DC Resistance (DCR)：43mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-55°C ~ 130°C
Inductance Frequency - Test：100 kHz
Mounting Type：Through Hole
Package / Case：Radial, Horizontal, 4 Leads (Open)
Supplier Device Package：-
Size / Dimension：1.102" L x 1.012" W (28.00mm x 25.70mm)
Height - Seated (Max)：0.630" (16.00mm)
Features：-

Fixed Inductors datasheet and documents for L301314A-151LHF

L301314A-151LHF

Fixed Inductors Overview

The L301314A-151LHF is a fixed inductor manufactured by ITG Electronics, Inc. It features an unshielded toroidal core design with a nominal inductance of 150 µH and a tolerance of ±15%. The component has a maximum DC resistance (DCR) of 43 mΩ and a current rating of 6 A. Saturation current is specified at 2.6 A. It utilizes a radial horizontal package with four open leads for through-hole mounting.

Fixed Inductors Feature Summary

Unshielded toroidal construction
Radial horizontal lead configuration
Through-hole mounting style

Fixed Inductors Applications

Power supply filtering
Signal processing circuits
General electronic equipment

Fixed Inductors Procurement Notes

Verify the specific manufacturer datasheet to confirm electrical parameters such as saturation current and DCR limits. Ensure the through-hole footprint matches the PCB layout requirements. Check for RoHS compliance status if required by project specifications. Confirm availability from authorized distributors to avoid counterfeit components.

Fixed Inductors Selection Notes

Select this component when a 150 µH inductance value is required with a 6 A current rating. The unshielded design may require careful placement to minimize magnetic interference with nearby components. Verify that the 43 mΩ DCR meets the efficiency requirements of the target circuit application.

Fixed Inductors Part Context

This part belongs to the L301314 series of fixed inductors from ITG Electronics. The series offers various inductance values and current ratings. The L301314A-151LHF specifically denotes the 150 µH variant within this product line.

Fixed Inductors Replacement Considerations

Cross-reference with other 150 µH toroidal inductors having similar current ratings and DCR values. Ensure mechanical compatibility with the existing PCB footprint before substitution.
