L955MYC-S

LED Indication - Discrete Overview

The L955MYC-S is a surface-mount yellow LED indicator from American Opto Plus LED, housed in a PLCC2 package with dimensions of 3.5 x 2.8 x 1.9 mm. It features a round lens with a flat top and a diameter of 2.20 mm. The component emits light at a peak wavelength of 593 nm and a dominant wavelength of 590 nm. Typical forward voltage is 2.1 V, with a luminous intensity of 680 mcd. The viewing angle is 120 degrees, and the lens transparency is clear.

LED Indication - Discrete Feature Summary

• Yellow emission with high luminous intensity for clear visual indication
• Standard PLCC2 surface-mount package for automated assembly compatibility
• Wide 120-degree viewing angle for broad visibility
• Clear lens design with flat top geometry

LED Indication - Discrete Applications

• General electronic equipment status indicators
• Consumer appliance control panels
• Industrial machinery signal lights
• Automotive interior lighting applications

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix to ensure correct binning and packaging configuration. Confirm that the PLCC2 package dimensions match your PCB footprint requirements. Check datasheet specifications for forward current limits and thermal management needs during operation. Ensure compatibility with standard SMT reflow profiles used in your manufacturing process.

LED Indication - Discrete Selection Notes

Choose this component when a compact, high-intensity yellow indicator is required for panel mounting. The PLCC2 form factor offers reliable soldering performance and mechanical stability. Consider the 120-degree viewing angle for applications requiring wide-area visibility. Evaluate the 2.1V forward voltage against your circuit drive capabilities.

LED Indication - Discrete Part Context

American Opto Plus LED manufactures a range of optoelectronic components including discrete LEDs and displays. The L955 series represents their surface-mount LED lineup designed for general indication purposes. This manufacturer has established production capabilities since 1973, focusing on quality LED products for various industrial and consumer markets.

LED Indication - Discrete Replacement Considerations

Cross-reference compatible PLCC2 yellow LEDs from other manufacturers if supply constraints exist. Verify electrical parameters such as forward voltage and luminous intensity to ensure functional equivalence. Check physical dimensions and pinout configurations to guarantee PCB compatibility without redesign.

LED Indication - Discrete FAQ

What is the typical forward voltage of the L955MYC-S?

The typical forward voltage is 2.1 V.

Does the L955MYC-S have a diffused or clear lens?

It features a clear lens with a round shape and flat top.
