LB T66G-U1BA-59-0-20-R33-Z

LED Indication - Discrete Overview

The LB T66G-U1BA-59-0-20-R33-Z is a blue surface-mount LED from the TOPLED Black series by ams OSRAM. It emits light at a peak wavelength of 465nm and a dominant wavelength of 470nm. The device features a forward voltage of 3.2V and operates with a viewing angle of 60 degrees. It utilizes a colorless lens with a diameter of 2.58mm and has a maximum height of 3.50mm. The component is housed in a 2-PLCC package.

LED Indication - Discrete Feature Summary

• Blue emission within the TOPLED Black series
• Integrated colorless lens for optical control
• Standard 2-PLCC surface-mount packaging

LED Indication - Discrete Applications

• General indicator lighting
• Electronic status signaling
• Consumer device illumination

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix to ensure correct wavelength and binning specifications. Confirm RoHS compliance status through official documentation before integration. Check moisture sensitivity levels and reflow soldering profiles against assembly requirements. Ensure the supplier provides valid traceability data for quality assurance purposes.

LED Indication - Discrete Selection Notes

Select this component for applications requiring standard blue indication with a compact footprint. Consider the 60-degree viewing angle for directional visibility needs. Evaluate the 3.2V forward voltage drop against available drive circuitry. Compare physical dimensions against board space constraints prior to finalizing the design.

LED Indication - Discrete Part Context

This part belongs to the TOPLED Black family, designed for high-reliability surface-mount applications. The series offers consistent performance across various industrial and consumer electronics sectors. It represents a standard solution for discrete LED indication tasks requiring robust construction.

LED Indication - Discrete Replacement Considerations

Cross-reference with other blue LEDs in the TOPLED series for mechanical compatibility. Verify electrical parameters such as forward voltage and current ratings match existing designs. Ensure lens dimensions and mounting pad layouts align with the target PCB footprint.
