LCMXO1200C-3M132I

Field Programmable Gate Array Overview

The LCMXO1200C-3M132I is a non-volatile, infinitely reconfigurable Field Programmable Gate Array (FPGA) from the MachXO family. It features 1200 logic elements and supports up to 101 I/Os in its 132-ball csBGA package. The device includes 6.4 Kbits of distributed RAM and one Embedded Block RAM (EBR) block providing 9.2 Kbits of memory. It operates with supply voltages of 1.2V, 1.8V, 2.5V, or 3.3V and contains one sysCLOCK PLL for clock management.

Field Programmable Gate Array Feature Summary

• Non-volatile architecture enabling instant-on operation without external configuration memory
• TransFR technology allowing in-field logic updates while the system remains operational
• Flexible sysIO buffers supporting multiple interface standards including LVDS and PCI

Field Programmable Gate Array Applications

• Glue logic implementation replacing complex CPLD designs
• Bus bridging and interface conversion between different protocol standards
• Power-up control and system initialization logic

Field Programmable Gate Array Procurement Notes

Verify the specific suffix 'M132' corresponds to the 132-ball csBGA package variant when sourcing. Confirm that the 'C' designation aligns with commercial temperature specifications required by the application environment. Ensure compatibility with the design toolchain used for MachXO programming.

Field Programmable Gate Array Selection Notes

Select this model for applications requiring moderate logic density with high I/O flexibility. The inclusion of an EBR block distinguishes it from lower-density variants lacking embedded memory. Consider the 132-ball package constraints regarding PCB real estate and thermal dissipation requirements for the target enclosure.

Field Programmable Gate Array Part Context

This component belongs to the MachXO family, which bridges the gap between traditional CPLDs and low-capacity FPGAs. It combines the security and instant-on capabilities of flash-based devices with the programmability of SRAM architectures. The family offers density migration options across 256 to 2280 LUT devices.

Field Programmable Gate Array Replacement Considerations

LCMXO1200E-3M132I
