LDFL015163VGQH0E

$21.78

Description：CMC 15.7MH 15A 2LN TH AEC-Q200
Series：FL-V
Mfr：Chemi-Con
Package：Bulk

SKU:bfaa89db268a Category: Common Mode Chokes Brand: Chemi-Con

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LDFL015163VGQH0E is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Chemi-Con. Its product description is CMC 15.7MH 15A 2LN TH AEC-Q200. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for LDFL015163VGQH0E

Description：CMC 15.7MH 15A 2LN TH AEC-Q200
Series：FL-V
Mfr：Chemi-Con
Package：Bulk
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：15A
DC Resistance (DCR) (Max)：15mOhm
Voltage Rating - DC：250V
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 130°C
Ratings：AEC-Q200
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：2.559" Dia (65.00mm)
Height (Max)：1.437" (36.50mm)
Package / Case：Horizontal, No Base, 6 PC Pin
Inductance @ Frequency：15.7 mH @ 100 kHz
Impedance @ Frequency：-
Qualification：-
Grade：-

Common Mode Chokes datasheet and documents for LDFL015163VGQH0E

LDFL015163VGQH0E

Common Mode Chokes Overview

The LDFL015163VGQH0E is a nanocrystalline common mode coil from the FL-V Series by Chemi-Con. It features an inductance of 15.7 mH at 100 kHz and supports a DC current rating of 15 A. The component has a maximum DC resistance of 0.015 ohms and operates within a temperature range of -40°C to 130°C. Designed for three-phase applications, it utilizes a nanocrystal alloy core with a diameter of 65 mm.

Common Mode Chokes Feature Summary

Utilizes nanocrystalline core material for high-performance filtering
Designed for three-phase common mode noise suppression
Supports high DC current ratings with low DC resistance

Common Mode Chokes Applications

Three-phase power line filtering
Industrial motor drive noise suppression
High-current AC/DC conversion stages

Common Mode Chokes Procurement Notes

Verify the specific datasheet version for the LDFL015163VGQH0E to confirm mechanical dimensions and mounting requirements. Ensure the operating environment stays within the specified -40°C to 130°C range. Check for SVHC compliance status as indicated in the latest documentation before integration into regulated products.

Common Mode Chokes Selection Notes

Select this component when high current handling and low impedance are required for three-phase systems. The nanocrystalline core offers superior performance compared to traditional ferrite cores at higher frequencies. Consider the 65 mm diameter for adequate clearance and thermal management in dense assemblies.

Common Mode Chokes Part Context

This part belongs to the FL-V Series of common mode chokes. It is manufactured by Nippon Chemi-Con Corporation. The series is characterized by the use of nanocrystalline materials to achieve high inductance values while maintaining low losses and high saturation current capabilities for industrial applications.
