LDFL020592VJUV0E is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Chemi-Con. Its product description is CMC 5.9MH 20A 2LN TH AEC-Q200. Review the specifications below when checking this part for your BOM.
Common Mode Chokes specifications for LDFL020592VJUV0E
- Description：CMC 5.9MH 20A 2LN TH AEC-Q200
- Series：FL-V
- Mfr：Chemi-Con
- Package：Bulk
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：20A
- DC Resistance (DCR) (Max)：5.7mOhm
- Voltage Rating - DC：700V
- Voltage Rating - AC：-
- Operating Temperature：-40°C ~ 130°C
- Ratings：AEC-Q200
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：1.969" Dia (50.00mm)
- Height (Max)：1.890" (48.00mm)
- Package / Case：Radial, Vertical (Open)
- Inductance @ Frequency：5.9 mH @ 100 kHz
- Impedance @ Frequency：-
- Qualification：-
- Grade：-
Common Mode Chokes datasheet and documents for LDFL020592VJUV0E
Common Mode Chokes Overview
The Chemi-Con LDFL020592VJUV0E is a nanocrystalline common mode filter choke designed for automotive applications. It features an inductance of 5.9 mH and supports a DC current rating of 20 A. The component has a maximum DC resistance of 5700 µohm and operates within a temperature range of -40°C to high temperatures, meeting AEC-Q200 standards. Its physical dimensions are 48 mm x 50 mm x 32.5 mm with a voltage rating of 700 VDC.
Common Mode Chokes Feature Summary
- Utilizes nanocrystalline alloy core material for effective noise suppression
- Complies with AEC-Q200 qualification standards for automotive reliability
- Engineered for high current handling capabilities up to 20 A
Common Mode Chokes Applications
- Automotive power line filtering
- Bus line transceiver protection
- High voltage DC circuit noise suppression
Common Mode Chokes Procurement Notes
Verify the specific datasheet version and mechanical drawings before integration. Confirm that the 48x50x32.5mm footprint matches the target PCB or chassis layout. Ensure the 20A current rating aligns with the system's peak load requirements. Check for any recent product change notices regarding material composition or manufacturing location changes.
Common Mode Chokes Selection Notes
Select this component when high inductance is required for low-frequency common mode noise attenuation in automotive environments. The nanocrystalline core offers superior performance compared to traditional ferrite cores at lower frequencies. Consider the physical size constraints due to the large housing. Verify thermal management needs given the high current capacity and potential power dissipation.
Common Mode Chokes Part Context
This part belongs to Chemi-Con's automotive-grade common mode coil series. It is specifically engineered to meet the rigorous reliability demands of modern vehicle electronics. The use of nanocrystalline technology allows for compact design while maintaining high performance in harsh electrical environments typical of automotive bus lines.
Common Mode Chokes Replacement Considerations
No direct substitute part numbers are publicly confirmed for this specific model.
