LDFW035132Y72H0E

Common Mode Chokes Overview

The LDFW035132Y72H0E is a radial leaded aluminum electrolytic capacitor manufactured by Nippon Chemi-Con. It features a capacitance of 1300 µF with a tolerance of ±20% at 20°C. The rated DC voltage is 35 V. The component operates within a temperature range of -40°C to +105°C. Key electrical characteristics include a maximum ripple current of 2.6 A at 120 Hz and a maximum impedance of 28 mΩ. The leakage current is specified at 4.68 mA after five minutes at rated voltage. Physical dimensions are 25 mm in diameter and 35 mm in height, with a terminal pitch of 10 mm.

Common Mode Chokes Feature Summary

• High capacitance density for efficient energy storage in compact radial packages
• Designed for stable operation across wide industrial temperature ranges up to 105°C
• Low impedance construction supporting high-frequency ripple current handling

Common Mode Chokes Applications

• DC-DC converter input and output filtering
• Power supply bulk capacitance stages
• Industrial control system power conditioning

Common Mode Chokes Procurement Notes

Verify the specific suffix codes against the official Nippon Chemi-Con datasheet to confirm exact physical dimensions and termination plating specifications. Ensure that the operating environment does not exceed the rated voltage or temperature limits defined in the product bulletin. Cross-reference the manufacturer's part number with authorized distributor catalogs to confirm availability and authenticity before procurement.

Common Mode Chokes Selection Notes

Select this component when high volumetric efficiency is required for radial leaded applications. The 35 V rating and 1300 µF value suit low-voltage power distribution networks. Consider the 2.6 A ripple current capability for switching regulator designs. Evaluate the 105°C temperature rating against ambient thermal conditions to ensure long-term reliability and adequate lifespan under continuous load.

Common Mode Chokes Part Context

This capacitor belongs to the radial leaded aluminum electrolytic series produced by Nippon Chemi-Con. The brand is a major global supplier of passive components, particularly known for aluminum electrolytic capacitors. This specific model represents a standard through-hole solution for general-purpose power electronics, balancing cost, size, and electrical performance for mainstream industrial and consumer applications.

Common Mode Chokes Replacement Considerations

Direct substitutes must match the 1300 µF capacitance, 35 V rating, and 25x35 mm form factor. Verify equivalent ripple current ratings and impedance values to maintain circuit stability. Alternative brands may offer similar specifications but require validation of pin compatibility and thermal derating curves.
