LF21064NTR

$2.02

Description：IC GATE DRVR HALF-BRIDGE 14SOIC
Series：-
Mfr：Littelfuse Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:8767716997f3 Category: Gate Drivers Brand: Littelfuse Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC GATE DRVR HALF-BRIDGE 14SOIC
Series：-
Mfr：Littelfuse Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Driven Configuration：Half-Bridge
Channel Type：Independent
Number of Drivers：2
Gate Type：IGBT, MOSFET (N-Channel)
Voltage - Supply：10V ~ 20V
Logic Voltage - VIL, VIH：0.6V, 2.5V
Current - Peak Output (Source, Sink)：290mA, 600mA
Input Type：Non-Inverting
Rise / Fall Time (Typ)：100ns, 25ns
Operating Temperature：-40°C ~ 125°C (TA)
Mounting Type：Surface Mount
Package / Case：14-SOIC (0.154", 3.90mm Width)
Supplier Device Package：14-SOIC
Grade：-
Qualification：-
High Side Voltage - Max (Bootstrap)：600 V

Download product information

LF21064NTR

Overview

The LF21064NTR is a high-side and low-side gate driver designed for IGBT applications. It features an input voltage range of 10-20V and supports drive currents up to 600mA. Key electrical parameters include a maximum offset voltage of 600V, a typical peak source current of 290mA, and a typical peak sink current of 600mA. The device utilizes HIN and LIN inputs.

Feature Summary

Integrated high-side and low-side driver architecture
Optimized for driving IGBT solid state switches
Supports standard input logic signals

Applications

IGBT gate control in power conversion circuits
Solid state switching systems
High voltage circuit protection interfaces

Procurement Notes

Verify the specific manufacturer datasheet for the LF21064NTR to confirm pinout compatibility and thermal requirements. Ensure the component matches the required 600V offset voltage specification for your application. Cross-reference the package type with your PCB layout constraints before finalizing procurement orders.

Selection Notes

Select this component when designing circuits requiring simultaneous high-side and low-side control for IGBTs. Consider the 600V offset capability and the specific peak source and sink current limits. Evaluate the 10-20V input range against your system's logic levels to ensure proper signal interfacing without additional level shifting.

Part Context

This part belongs to Littelfuse's series of gate drivers intended for power electronics. It complements their portfolio of non-punch through (NPT) IGBTs and other power semiconductors. The device facilitates efficient energy transfer by providing robust switching control for high-voltage industrial and automotive applications.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify functional equivalence with other high/low-side drivers if substitution is necessary.
