Product Detailed Parameters
- Description：XTAL OSC TCXO 40.0000MHZ HCMOS
- Series：CFPT-9006
- Mfr：IQD Frequency Products
- Package：Strip
- Base Resonator：Crystal
- Type：TCXO
- Frequency：40 MHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：3.3V
- Frequency Stability：±1ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：2mA
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：10-SMD Module
- Size / Dimension：0.276" L x 0.197" W (7.00mm x 5.00mm)
- Height - Seated (Max)：0.089" (2.25mm)
Download product information
Overview
LFPTXO000009BULK is a temperature-compensated crystal oscillator (TCXO) manufactured by IQD Frequency Products. It operates at a nominal frequency of 40 MHz with HCMOS output format. The device supports a supply voltage range of 2.97 V to 3.63 V and features surface mount packaging in a 10-pin configuration. It includes enable/disable functionality and tri-state capabilities, designed for applications requiring stable clock references within specified thermal conditions.
Feature Summary
- Temperature compensation utilizing Rakon Pluto ASIC technology for extended range stability
- HCMOS output interface with enable/disable and tri-state control functions
- Low power consumption suitable for mobile and battery-operated applications
- Surface mount construction compatible with automated assembly processes
Applications
- Mobile communication equipment requiring stable clock references
- Data transmission systems needing precise timing signals
- Consumer electronics utilizing low-power oscillators
- Industrial control systems operating within specified temperature ranges
Procurement Notes
Verify the specific part number suffix against official IQD documentation to confirm exact electrical parameters and package variations. Ensure compatibility with system voltage requirements and thermal specifications before integration. Cross-reference datasheet revisions to confirm RoHS compliance status and manufacturing origin details.
Selection Notes
Select this component when a 40 MHz TCXO with HCMOS output is required for space-constrained designs. Consider the 10-pin SMD footprint for PCB layout constraints. Evaluate the operating temperature range against environmental conditions. Confirm that the enable/disable feature aligns with system power management strategies.
Part Context
This model belongs to the CFPT-9000 series of SMD TCXOs and TCVCXOs from IQD Frequency Products. The series utilizes Rakon Pluto ASIC technology for single-chip oscillator and analogue compensation. It represents a solution for applications demanding high stability and low power consumption in compact surface mount packages.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Verify pinout compatibility and electrical specifications if considering alternative manufacturers. Consult IQD Frequency Products directly for current obsolescence status or recommended replacements.
