LFSPXO050283REEL

Overview

The LFSPXO050283REEL is a standard clock oscillator from the IQD Frequency Products LFSPXO series. It operates at a frequency of 32.768 kHz with CMOS output format. The device requires a supply voltage of 3.3V and features a load capacitance of 15 pF. It is designed for surface mount (SMD/SMT) applications and is supplied in reel packaging.

Feature Summary

• Provides stable timing signals via CMOS output interface
• Designed for surface mount technology integration
• Operates on a single 3.3V power supply

Applications

• Real-time clock circuits
• Microcontroller system timing
• Low-frequency digital logic synchronization

Procurement Notes

Verify the specific package dimensions and lead configuration against the official datasheet to ensure compatibility with the target PCB footprint. Confirm that the operating temperature range meets the environmental requirements of the final assembly. Ensure the supply voltage tolerance aligns with the system power rail specifications before procurement.

Selection Notes

Select this component when a precise 32.768 kHz reference is required for low-power or real-time applications. Consider the CMOS output swing and drive capability relative to the load circuit. Evaluate the physical size constraints against the available board space, as surface mount packages vary in dimensions across the product family.

Part Context

This part belongs to the LFSPXO series of standard oscillators manufactured by IQD Frequency Products. The series offers various frequencies and packages tailored for commercial and industrial electronics. This specific model provides a common sub-MHz frequency suitable for timekeeping and control functions within embedded systems.
