LFSPXO071976

Overview

The LFSPXO071976 is a standard clock oscillator from the IQD Frequency Products series, designed for surface-mount applications. It operates at a nominal frequency of 32.768 kHz with a frequency stability of +/-30 ppm. The device utilizes CMOS output format and requires a nominal supply voltage of 1.8 V. Encased in a compact SMD package measuring 1.6 mm x 1.2 mm, it supports standby or power-down functionality to minimize energy consumption during idle periods.

Feature Summary

• Supports standby mode for power reduction
• CMOS output signal compatibility
• Compact surface-mount footprint

Applications

• Real-time clock circuits
• Low-power embedded systems
• Portable electronic devices

Procurement Notes

Verify the specific package dimensions and electrical characteristics against the official datasheet before integration. Confirm that the supply voltage requirements align with the target system design. Ensure the frequency stability meets the application's timing accuracy needs. Check RoHS compliance status if required by project specifications.

Selection Notes

Choose this component when a low-frequency, high-stability reference is needed for timekeeping functions. The 1.8V supply requirement suits battery-operated or low-voltage logic environments. Consider the small form factor for space-constrained PCB layouts. Evaluate the standby feature if power management is critical for the end product.

Part Context

This part belongs to the standard oscillator category within IQD Frequency Products' portfolio. It complements other quartz crystal and resonator solutions offered by the manufacturer. The product line targets industries requiring reliable frequency control components for consumer, industrial, and automotive electronics.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
