LFSPXO073706

Overview

The LFSPXO073706 is a standard CMOS clock oscillator manufactured by IQD Frequency Products. It operates at a nominal frequency of 32.768 kHz with a supply voltage range of 1.8V to 3.63V. The device features an enable/disable function and is housed in a compact 4-SMD, no-lead package measuring 2.00mm x 1.60mm. It supports a maximum operating temperature of 125°C.

Feature Summary

• Integrated enable and disable control functionality for power management
• CMOS output format compatible with digital logic circuits
• Compact surface-mount package design suitable for space-constrained applications

Applications

• Real-time clock circuits requiring low-frequency timing references
• Battery-powered portable electronic devices utilizing power-saving modes
• Embedded systems requiring precise timekeeping synchronization

Procurement Notes

Verify the specific suffix codes against the manufacturer's latest documentation to ensure compatibility with required voltage levels and packaging formats. Confirm that the enable/disable pin configuration aligns with the target system's control logic requirements before finalizing procurement decisions.

Selection Notes

Select this component when a low-power, small-footprint oscillator is needed for timekeeping applications. Ensure the system voltage falls within the specified 1.8V to 3.63V range. Consider the thermal performance if the operating environment exceeds standard commercial temperatures, as this model supports up to 125°C.

Part Context

This part belongs to the LFSPXO series of standard crystal oscillators from IQD Frequency Products. It is designed for general-purpose timing applications where size and power consumption are critical factors. The series offers various frequencies and packages to meet diverse design constraints.

Replacement Considerations

Check for direct cross-references in distributor databases. Verify pinout compatibility and electrical specifications if substituting with other 32.768 kHz SMD oscillators.
