LFSPXO084273

Overview

The LFSPXO084273 is a standard crystal oscillator manufactured by IQD Frequency Products. It operates at a nominal frequency of 125 MHz and utilizes LVDS output format for high-speed signal integrity. The device is designed for surface mount installation within a compact 4-SMD, no-lead package. It functions reliably across an extended industrial temperature range from -40°C to +85°C. The component requires a supply voltage of 3.3 V to operate correctly.

Feature Summary

• Provides stable clock signals using LVDS output technology
• Supports surface mount assembly in a small form factor
• Operates effectively within wide industrial temperature limits

Applications

• High-speed digital communication interfaces
• Data acquisition systems requiring precise timing
• Industrial control equipment with strict environmental demands

Procurement Notes

Verify the specific part number against official IQD Frequency Products documentation to ensure compatibility with system requirements. Confirm that the LVDS output format aligns with the receiving circuitry specifications. Check the operating temperature range to ensure suitability for the intended environment. Validate the physical package dimensions against the printed circuit board layout constraints before finalizing procurement decisions.

Selection Notes

Select this component when a high-frequency clock source is required for sensitive digital applications. The LVDS output ensures low noise and reliable transmission over short distances. Consider the 3.3 V supply requirement and the specific package size during the design phase. Ensure the selected variant meets the necessary thermal performance standards for the target application environment.

Part Context

This oscillator belongs to the LFSPXO series from IQD Frequency Products, which specializes in precision timing solutions. The series offers various frequencies and output formats tailored for demanding electronic designs. As part of the Wurth Group, IQD provides components widely used in automotive, industrial, and computing sectors for critical clock generation tasks.

Replacement Considerations

Consult official manufacturer substitution lists for verified equivalent parts. Cross-reference pinout configurations and electrical characteristics carefully. Generic replacements may not match the specific LVDS drive strength or frequency stability requirements.
