LFSPXO084282

Overview

The LFSPXO084282 is a standard clock oscillator manufactured by IQD Frequency Products. It operates at a nominal frequency of 200.0 MHz and utilizes LVPECL output format. The device is powered by a 3.3 V supply voltage and features a compact 4-SMD, No Lead package. This component is designed for high-speed digital applications requiring precise timing signals.

Feature Summary

• Generates a stable 200.0 MHz signal using LVPECL output interface
• Operates with a single 3.3 V power supply
• Utilizes a small form factor 4-SMD, No Lead surface mount package

Applications

• High-speed data communication systems
• Digital signal processing circuits
• Network infrastructure equipment

Procurement Notes

Verify the specific part number LFSPXO084282 against official IQD Frequency Products documentation to confirm current availability and manufacturing status. Ensure that the LVPECL output requirements and 3.3 V supply constraints align with the target system design before procurement. Cross-reference package dimensions and pinout details with the latest datasheet to guarantee mechanical compatibility.

Selection Notes

Select this component when a 200.0 MHz clock source with LVPECL outputs is required in a space-constrained design. The 3.3 V operation makes it suitable for modern low-voltage digital logic families. Consider the 4-SMD, No Lead package for automated surface mount assembly processes. Evaluate thermal management needs based on the operating environment and power dissipation characteristics defined in the official specifications.

Part Context

This oscillator belongs to the LFSPXO series from IQD Frequency Products, which offers various standard clock oscillators. The series provides different frequencies, output formats, and package sizes to meet diverse electronic design requirements. The LFSPXO084282 specifically addresses the need for high-frequency performance in a miniature footprint.

Replacement Considerations

Consult official IQD Frequency Products substitution guides or distributor cross-reference tools for compatible alternatives. Verify that any substitute matches the 200.0 MHz frequency, LVPECL output type, 3.3 V supply, and 4-SMD, No Lead package dimensions.
