LFTCXO070898REEL

Overview

The LFTCXO070898REEL is a temperature-compensated crystal oscillator (TCXO) manufactured by IQD Frequency Products. It operates at a nominal frequency of 38.4 MHz with a clipped sine wave output format. The device requires a supply voltage of 3.3 V and is housed in a compact 6-SMD, no-lead package. This component provides stable clock signals suitable for precision timing applications requiring low phase noise and high frequency stability.

Feature Summary

• Temperature-compensated design ensures frequency stability across varying thermal conditions
• Clipped sine wave output format supports analog-compatible circuit interfaces
• Compact surface-mount package facilitates automated assembly and space-constrained designs

Applications

• Precision timing circuits in communication systems
• Clock generation for digital signal processing units
• Test and measurement equipment requiring stable reference frequencies

Procurement Notes

Verify the specific suffix and reel configuration against the manufacturer's current documentation to ensure compatibility with existing inventory or production lines. Confirm RoHS compliance status and lead-free specifications as required by regional regulations before finalizing procurement orders.

Selection Notes

Select this component when a 38.4 MHz reference is required with clipped sine wave output. Ensure the system power supply matches the 3.3 V requirement. Verify that the 6-SMD package dimensions fit within the available PCB real estate and that the operating temperature range meets the environmental demands of the target application.

Part Context

This part belongs to the TCXO category from IQD Frequency Products, designed for applications needing better stability than standard crystals but without the complexity of OCXOs. It complements other oscillators in the portfolio by offering a balance of performance and size for embedded timing solutions.

Replacement Considerations

Check for direct substitute part numbers listed in the manufacturer's obsolescence notices or cross-reference guides. Ensure any replacement maintains the 38.4 MHz frequency, 3.3 V supply, and clipped sine wave output to guarantee functional equivalence.
