LFTCXO079057

Overview

The LFTCXO079057 is a temperature-compensated crystal oscillator (TCXO) manufactured by IQD Frequency Products. It operates at a nominal frequency of 16.369 MHz and utilizes a clipped sine wave output format. The device is designed for surface mount installation in a compact four-terminal, no-lead package. It functions within a supply voltage range centered around 1.8V, ensuring compatibility with low-voltage digital systems. The component is RoHS compliant and engineered to provide stable clock signals across specified operating conditions.

Feature Summary

• Temperature compensation ensures frequency stability across varying thermal environments
• Clipped sine wave output format suitable for specific receiver inputs
• Compact surface-mount footprint facilitates automated PCB assembly

Applications

• Wireless communication modules requiring precise timing references
• Portable electronic devices utilizing low-voltage power supplies
• Industrial control systems needing reliable clock synchronization

Procurement Notes

Verify the exact frequency tolerance and aging specifications against the official IQD datasheet before integration. Confirm that the clipped sine wave output matches the input requirements of the target circuitry. Ensure the selected package variant aligns with the designated footprint on the printed circuit board layout to prevent soldering defects.

Selection Notes

Select this component when a 16.369 MHz reference is required with minimal form factor constraints. Consider the clipped sine wave output characteristics for compatibility with downstream logic or mixers. Evaluate the 1.8V supply requirement against available system rails to ensure adequate headroom and power efficiency during continuous operation.

Part Context

This TCXO belongs to IQD's portfolio of precision frequency control products, which serve diverse sectors including automotive, industrial, and consumer electronics. The manufacturer leverages extensive experience in quartz technology to deliver components that meet stringent reliability standards. This specific model represents a solution for applications demanding high stability in space-limited designs.

Replacement Considerations

Consult the official IQD replacement guide for direct equivalents. Verify pinout compatibility and electrical parameter alignment before substituting with alternative oscillators from other manufacturers.
