LFXP2-5E-7QN208C

Field Programmable Gate Array Overview

The LFXP2-5E-7QN208C is a member of the LatticeXP2 family, featuring 5 K logic cells and internal Flash configuration. It includes 9 embedded block RAM blocks (166 Kbits) and 3 sysDSP blocks with 12 18x18 multipliers. The device supports up to four PLLs and two DLLs, offering DDR/DDR2 support at 400 Mbps. It operates in a 208-pin QN package.

Field Programmable Gate Array Feature Summary

• Instant-on capability via non-volatile Flash memory
• FlashBAK technology for block RAM data backup
• TransFR live update and AES encryption support

Field Programmable Gate Array Applications

• High-volume low-cost applications
• System control functions
• I/O expansion and bridging

Field Programmable Gate Array Procurement Notes

Verify the specific suffix 'E' against official datasheets to confirm temperature range and voltage specifications. Ensure the '7' speed grade matches design timing requirements. Confirm the 'QN208' package type aligns with PCB layout constraints. Cross-reference the manufacturer's current product status to ensure availability.

Field Programmable Gate Array Selection Notes

Select this part for designs requiring instant-on functionality without external configuration memory. Consider the 5 K LUT capacity for moderate complexity logic. Evaluate the 166 Kbits of embedded RAM against buffer requirements. Verify that the 208-pin QN package fits the mechanical envelope.

Field Programmable Gate Array Part Context

This component belongs to the LatticeXP2 family, which integrates Flash memory for instant-on operation. It targets high-volume, cost-sensitive markets. The family offers a balance of logic density and power efficiency. It supports secure boot and live updates through TransFR technology.

Field Programmable Gate Array Replacement Considerations

Check for LFXP2-5 variants with different speed grades or packages. Verify compatibility with LFE2 series if external Flash is used. Ensure pinout and I/O standards match existing system requirements.
